Description
The Hurricane SA 4SA8/8 borehole submersible pump end requires a 1.1Kw submersible motor to drive it and is capable of delivering up to 60L/min at a depth of 47m.
Operating Conditions
- Maximum fluid temperature : up to 35°C
- Maximum sand content : 0.25%
- Minimum borehole diameter : 4″ (10.16cm)
Motor & Pump
Three Phase : 380V – 415V 1.1KW 2HP / 50Hz or Single Phase 220-240V 1.1KW 1.5HP Motor
Equip with a three phase 380V or 220V automatic or standard control box 1.1KW 1.5HP (water level sensors)
Warranty : 12 Month
According to our general sales conditions
Specifications
- Speed : 2850RPM
- Power : 1.1KW
- Power : 1.5HP
- Outlet : 40mm
- Pump Diameter : 100mm
- Pump Length : 580mm
- Pump Wieght : 4.5KG
| Output | 60L/min | 120L/min | 180L/min |
| Depth | 47m | 39m | 17m |
Water Delivery Pump Curve
