Description
The Hurricane SA 4SA6/26 borehole submersible pump end requires a 3KW submersible motor to drive it and is capable of delivering up to 20L/min at a depth of 175m.
Operating Conditions
- Maximum fluid temperature : up to 35°C
- Maximum sand content : 0.25%
- Minimum borehole diameter : 4″ (10.16cm)
Motor & Pump
Three Phase : 380V – 415V 3KW 4HP / 50Hz
Equip with either a standard (manual) or an automatic control box 3KW 4HP (water level sensors)
Warranty : 12 Month
According to our general sales conditions
Specifications
- Speed : 2850RPM
- Power : 3KW
- Power : 4HP
- Outlet : 40mm
- Pump Diameter : 100mm
- Pump Length : 1230mm
- Pump Weight : 10,3KG
| Output | 20L/min | 100L/min | 140L/min |
| Depth | 175m | 117m | 51m |
Water Delivery Pump Curve
