Description
The Hurricane SA 4SA16/12 borehole submersible pump end requires a 3Kw submersible motor to drive it and is capable of delivering up to 100L/min at a depth of 66m.
Operating Conditions
- Maximum fluid temperature : up to 35°C
- Maximum sand content : 0.25%
- Minimum borehole diameter : 4″ (10.16cm)
Motor & Pump
Three Phase : 380V – 415V 3KW 4HP / 50Hz
Equip with an automatic control box 3KW 4HP (water level sensors)
Warranty : 12 Month
According to our general sales conditions
Specifications
- Speed : 2850RPM
- Power : 3KW
- Power : 4HP
- Outlet : 50mm
- Pump Diameter : 110mm
- Pump Length : 1240mm
- Pump Wieght : 10.8KG
| Output | 100L/min | 200L/min | 300L/min |
| Depth | 66m | 53m | 36m |
Water Delivery Pump Curve
