Description
The Hurricane SA 6SP46-8 borehole 6″ submersible pump end requires a 13 KW motor to drive it and is capable of delivering up to 500L/min at a depth of 86 metres.
Operating Conditions
- Maximum fluid temperature : up to +50°C
- Maximum sand content : 0.25%
- Maximum Immersion : 100m
- Minimum borehole diameter : 6″ (15.24cm)
Motor & Pump
Three Phase : 380V – 415V 13KW 17.5HP / 50Hz
Warranty : 12 Month
According to our general sales conditions
Specifications
- Speed : 2850RPM
- Power : 13KW
- Power : 17.5HP
- Pump Diameter : 150mm
- Pump Length : 1260mm
- Pump Weight : 21KG
| MODEL | KW | HP | DELIVERY | ||||||||||||
| L/HOUR | 0 | 6000 | 12000 | 18000 | 24000 | 30000 | 36000 | 42000 | 48000 | 54000 | 60000 | 66000 | |||
| L/MIN | 0 | 100 | 200 | 300 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 | 1100 | |||
| 6SP46-5 | 7.5 | 10 | HEAD (m) | 67 | 66 | 64 | 62 | 58 | 54 | 50 | 46 | 41 | 35 | 27 | 18 |
| 6SP46-7 | 11 | 15 | 94 | 92 | 90 | 86 | 81 | 76 | 70 | 64 | 57 | 48 | 38 | 25 | |
| 6SP46-8 | 13 | 17.5 | 107 | 105 | 102 | 98 | 93 | 86 | 80 | 73 | 65 | 55 | 43 | 29 | |
| 6SP46-9 | 15 | 20 | 121 | 118 | 115 | 111 | 104 | 97 | 90 | 82 | 73 | 62 | 49 | 32 | |
| 6SP46-10 | 15 | 20 | 134 | 131 | 128 | 123 | 116 | 108 | 100 | 91 | 81 | 69 | 54 | 36 | |
| 6SP46-12 | 18.5 | 25 | 161 | 157 | 154 | 148 | 139 | 130 | 120 | 109 | 97 | 83 | 65 | 43 | |
| 6SP46-14 | 22 | 30 | 188 | 183 | 179 | 172 | 162 | 151 | 140 | 127 | 113 | 97 | 76 | 50 | |
Water Delivery Pump Curve
