Description
The Hurricane SA 6SP30-7 borehole 6″ submersible pump end requires a 7.5 KW motor to drive it and is capable of delivering up to 400L/min at a depth of 64 metres.
Operating Conditions
- Maximum fluid temperature : up to +50°C
- Maximum sand content : 0.25%
- Maximum Immersion : 100m
- Minimum borehole diameter : 6″ (15.24cm)
Motor & Pump
Three Phase : 380V – 415V 7.5KW 10HP / 50Hz
Warranty : 12 Month
According to our general sales conditions
Specifications
- Speed : 2850RPM
- Power : 7.5KW
- Power : 10HP
- Pump Diameter : 150mm
- Pump Length : 1020mm
- Pump Weight : 17KG
| Model | Motor Power | Delivery N @ 2850 r/min | ||||||||||
| 6SP30 Series | KW | HP | Q | M3/h | 0 | 6 | 12 | 18 | 24 | 30 | 36 | 42 |
| L/min | 0 | 100 | 200 | 300 | 400 | 500 | 600 | 700 | ||||
| 6SP30/7 | 7.5 | 10 | H(m) | 80 | 77 | 74 | 70 | 64 | 55 | 43 | 28 | |
| 6SP30/8 | 7.5 | 10 | 91 | 89 | 84 | 77 | 71 | 61 | 46 | 28 | ||
| 6SP30/10 | 9.2 | 12.5 | 114 | 111 | 106 | 99 | 92 | 79 | 62 | 41 | ||
| 6SP30/12 | 11 | 15 | 137 | 133 | 127 | 119 | 110 | 95 | 74 | 49 | ||
| 6SP30/14 | 13 | 17.5 | 160 | 155 | 148 | 139 | 129 | 110 | 87 | 57 | ||
| 6SP30/16 | 15 | 20 | 183 | 177 | 169 | 159 | 147 | 126 | 99 | 65 | ||
| 6SP30/20 | 18.5 | 25 | 229 | 221 | 211 | 199 | 184 | 158 | 124 | 81 | ||
| 6SP30/24 | 22 | 30 | 275 | 266 | 254 | 239 | 221 | 189 | 149 | 98 | ||
Water Delivery Pump Curve
